XP 8000.1
At the pinnacle of performance and innovation, we proudly present the XP line—an impressive evolution in your audio experience. Designed with state-of-the-art technology and enhanced by artificial intelligence, XP amplifiers embody the core DNA of SounDigital: innovation, excellence, and precision.
The XP line delivers exceptional audio performance, combining advanced engineering with superior components to ensure reliability and remarkably faithful sound clarity. Its compact and versatile design allows seamless integration into a wide range of applications, meeting diverse needs with efficiency and practicality.
Whether you’re an audiophile or a casual listener, XP amplifiers elevate your audio experience, striking the perfect balance between cutting-edge technology and exceptional quality. With the XP line, hear sound as it was meant to be heard.
Instruction manualGeneral Specifications
+
-
XP 8000.1 - 1 OHM
Power RMS @ 4Ω: 3520W
Power RMS @ 2Ω: 5300W
Power RMS @ 1Ω: 8000WXP 8000.1 - 2 OHMS
Power RMS @ 4Ω: 5300W
Power RMS @ 2Ω: 8000W
Power RMS @ 1Ω: N/AFrequency Response (-3dB)
1Ω: 5Hz ~ 6kHz
2Ω: 5Hz ~ 6kHzSubsonic filter (12dB/oitava)
1Ω: 5Hz ~ 40Hz
2Ω: 5Hz ~ 40HzLow Pass filter (12dB/octave)
1Ω: 50Hz ~ 6kHz
2Ω: 50Hz ~ 6kHzBass Boost
1Ω: 0dB ~ 12dB @ 50Hz
2Ω: 0dB ~ 12dB @ 50HzOperating Voltage
1Ω: 9V ~ 16V
2Ω: 9V ~ 16VSNR
1Ω: 82dB
2Ω: 82dBInput Sensitivity (RCA)
1Ω: 0.2V ~ 2V
2Ω: 0.2V ~ 2VInput Sensitivity (High Level input)
1Ω: 1.5V ~ 15V
2Ω: 1.5V ~ 15VCurrent draw (music)
1Ω: 334A
2Ω: 334ACurrent draw (max.)
1Ω: 668A
2Ω: 668ATotal efficiency
1Ω: 81%
2Ω: 81%Damping factor (@100Hz nominal impedance)
1Ω: >2000
2Ω: >2000Power cable
1Ω: 70mm² (000 AWG)
2Ω: 70mm² (000 AWG)Speaker cable
1Ω: 2 x 16mm² (5 AWG)
2Ω: 2 x 16mm² (5 AWG)Remote cable
1Ω: 1.5mm² (15 AWG)
2Ω: 1.5mm² (15 AWG)Recommended Fuse* (music)
1Ω: 400A
2Ω: 400ARecommended battery (minimum)
1Ω: 400Ah
2Ω: 400AhWidth
11.78"
Length
7.10"
Height
2.52"
Weight
9.52 lb
