XP 2400.4
At the pinnacle of performance and innovation, we proudly present the XP line—an impressive evolution in your audio experience. Designed with state-of-the-art technology and enhanced by artificial intelligence, XP amplifiers embody the core DNA of SounDigital: innovation, excellence, and precision.
The XP line delivers exceptional audio performance, combining advanced engineering with superior components to ensure reliability and remarkably faithful sound clarity. Its compact and versatile design allows seamless integration into a wide range of applications, meeting diverse needs with efficiency and practicality.
Whether you’re an audiophile or a casual listener, XP amplifiers elevate your audio experience, striking the perfect balance between cutting-edge technology and exceptional quality. With the XP line, hear sound as it was meant to be heard.
Instruction manualGeneral Specifications
+
-
XP 2400.4 - 2 OHMS
Power RMS @ 4Ω: 4 x 261W
Power RMS @ 2Ω: 4 x 396W
Power RMS @ 1Ω: 4 x 600W
Power RMS (Bridge) @ 4Ω: 2 x 792W
Power RMS (Bridge) @ 2Ω: 2 x 1200WXP 2400.4 - 4 OHMS
Power RMS @ 4Ω: 4 x 396W
Power RMS @ 2Ω: 4 x 600W
Power RMS @ 1Ω: N/A
Power RMS (Bridge) @ 4Ω: 2 x 1200W
Power RMS (Bridge) @ 2Ω: N/AFrequency Response (-3dB)
2Ω: 5Hz ~ 22kHz
4Ω: 5Hz ~ 24kHzHigh Pass filter (12dB/octave)
2Ω: 45Hz ~ 850Hz
4Ω: 45Hz ~ 850HzLow Pass filter (12dB/octave)
2Ω: 45Hz ~ 850Hz
4Ω: 45Hz ~ 850HzBass Boost
2Ω: N/A
4Ω: N/AOperating Voltage
2Ω: 9V ~ 16V
4Ω: 9V ~ 16VSNR
2Ω: 100dB
4Ω: 92dBInput Sensitivity (RCA)
2Ω: 0.2V ~ 2V
4Ω: 0.2V ~ 2VInput Sensitivity (High Level input)
2Ω: 1.5V ~ 15V
4Ω: 1.5V ~ 15VCurrent draw (music)
2Ω: 98A
4Ω: 98ACurrent draw (max.)
2Ω: 195A
4Ω: 195ATotal Efficiency
2Ω: 82%
4Ω: 82%Damping Factor (@100Hz nominal impedance)
2Ω: 200
4Ω: 200Power cable
2Ω: 21mm² (4 AWG)
4Ω: 21mm² (4 AWG)Speaker cable
2Ω: 2 x 2.5mm² (13 AWG)
4Ω: 2 x 2.5mm² (13 AWG)Remote cable
2Ω: 1.5mm² (15 AWG)
4Ω: 1.5mm² (15 AWG)Recommended Fuse* (music)
2Ω: 120A
4Ω: 120ARecommended battery (minimum)
2Ω: 120Ah
4Ω: 120AhWidth
8.99"
Length
5.35''
Height
2.22''
Weight
4.18 lb
