BassTronik 8000.1
The BassTronik 8000.1 is an amplifier with an ultra-compact and modern design that delivers 8000W RMS of power in 1 channel.
The amplifier features exclusive and patented technologies, specially developed to ensure precise, deep, and powerful sub-bass, making the sound experience cleaner and more faithful, in addition to offering exceptional performance and efficiency even in the most daring projects.
Available in versions:
Instruction manualGeneral Specifications
+
-
BassTronik 8000.1 - 2 OHMS
Power @ 4Ω: 1 x 5300W
Power @ 2Ω: 1 x 8000W
Power @ 1Ω: 1 x N/ABassTronik 8000.1 - 1 OHM
Power @ 4Ω: 1 x 3800W
Power @ 2Ω: 1 x 5300W
Power @ 1Ω: 1 x 8000WFrequency Response (-3dB):
5Hz ~ 250Hz
Subsonic Filter (12dB/octave):
5Hz ~ 40Hz
Low Pass Filter (12dB/octave):
50Hz ~ 250Hz
Bass Boost:
0dB ~ 10dB @ 35Hz
Operating Voltage:
10V ~ 16V
SNR:
>90dB
Input Sensitivity (RCA):
0.2V ~ 2V
Input Sensitivity (High Level input):
1.5V ~ 15V
Current Draw (music):
2Ω: 382.6A
1Ω: 387.1ACurrent Draw (max.):
2Ω: 765.2A
1Ω: 774.2ATotal Efficiency:
2Ω: 83%
1Ω: 82%Damping Factor (@100Hz nominal impedance):
>2000
Power Cable:
2 x 70mm² (00 AWG)
Speaker Cable:
10mm² (7 AWG)
Remote Cable:
1.5mm² (15 AWG)
Recommended Fuse* (music):
2 x 200A
Recommended Battery (minimum):
450Ah
Width:
7.1''
Lenght:
12.2''
Height:
2.5''
Weight:
8.79 lb
