BassTronik 1600.1 - 4 OHMS

Power @ 4Ω: 1 x 1600W
Power @ 2Ω: 1 x N/A
Power @ 1Ω: 1 x N/A

BassTronik 1600.1 - 2 OHMS

Power @ 4Ω: 1 x 1000W
Power @ 2Ω: 1 x 1600W
Power @ 1Ω: 1 x N/A

BassTronik 1600.1 - 1 OHM

Power @ 4Ω: 1 x 650W
Power @ 2Ω: 1 x 1000W
Power @ 1Ω: 1 x 1600W

Frequency Response (-3dB):

5Hz ~ 250Hz

Subsonic filter (12dB/octave):

5Hz ~ 40Hz

Low Pass filter (12dB/octave):

50Hz ~ 250Hz

Bass Boost:

0dB ~ 10dB @ 35Hz

Operating Voltage:

10V ~ 16V

SNR:

4Ω: 90.8dB
2Ω: 88.5dB
1Ω: 90.2dB

Input Sensitivity (RCA):

0.2V ~ 2V

Input Sensitivity (High Level input):

1.5V ~ 15V

Current draw (music):

4Ω: 77.4A
2Ω: 77.5A
1Ω: 82A

Current draw (max.):

4Ω: 154.8A
2Ω: 155A
1Ω: 164A

Total efficiency:

4Ω: 83.8%
2Ω: 84.5%
1Ω: 85%

Damping factor (@100Hz nominal impedance):

>2000

Power cable:

16mm² (5 AWG)

Speaker Cable:

4Ω: 2.5mm² (13 AWG)
2Ω: 2.5mm² (13 AWG)
1Ω: 4.0mm² (11 AWG)

Remote Cable:

1.5mm² (15 AWG)

Recommended Fuse (music):

100A

Recommended battery (minimum):

120Ah

Width:

5.4''

Lenght:

7.1''

Height:

2.2''

Weight:

2.71 lb
